Quick Details

  • Place of Origin: Beijing, China (Mainland)
  • Brand Name: JHPK
  • Model Number: A9000
  • After-sales Service Provided: Overseas third-party support available
  • product name: 2014 newest CE polyurethane spray foam machine JHPK-A9000 for sale
  • Ratio of raw materials: 1:1
  • Viscosity range: 200~1000CPS
  • Output of raw materials: 2~8kg/ min
  • Heating power: 4500W*2
  • Heating temperature range: 0℃~90℃
  • Power source: 3-phase 4-wires
  • Output pressure: 9~18 Mpa
  • Dimension: 930mm*800mm*1210mm

Packaging & Delivery

Packaging Details plywood tray
Delivery Time have in stock

The newest promoted high performance JHPK-A9000 pneumatic ultrahigh pressure spraying & injection equipment with double component system can be applied under various construction situations and suitable for multiple double component materials, such as polyurea elastomer, polyurethane all-water foam, polyurethane foam material, polyurethane adhesive and sealants.



The equipment can be applied in the fields of architecture, highway, railway, automobile, watercraft, mining petroleum, electrical industry, food industry and etc.;



Having the complete independent intellectual property rights in design and production, several key techniques have applied national patents.



Super power with high efficient heating function can meet applications requirements with different materials and have multi-use of one machine;



The booster pump is completely pneumatic controlled with simple structure, reliable operation which can be operated without electricity;



The unique protection design for the black material anti-solidification and reset function when shut down realizes the dual protection for the shaft of the booster pump.



The lifetime of the equipment is greatly enhanced with the application of the high-performance dynamic and static sealing material and the design of the adjustable self-compensation sealing structure;



Straight platoon-type gas path and external pneumatic integrated control system makes the operating action fast and sensitive with low fault rate and is convenient for inspection and maintenance;



The delicate coupling structure enables the power transmission steady and reliable avoiding the adverse the effects to the pump shaft due to the concentricity problem;



The professional design of overfilling material backflow valve realizes the modularization for each functional component of the booster pump which is easy for the fault judgment and maintenance;



The special armoured temperature sensor inside the heater can collect the temperature signal at any time, makes the overshooting value of heating obtain a good control;



The flagelliform armoured temperature sensor inside the heating hose makes the collection of the temperature data more sensitive and accurate without signal losing;



The professional and special-made heating hoses make the heating even and reliable. The hoses are safe and durable with full closed water-proof connection with the external cover of the heat insulation layer and anti-abrasion layer;



The unique design in the silencing and noise reduction makes the equipment operation more quiet;



The big wheel design and application makes the moving of the equipment more easily and freely under complicate ground circumstances;



The compact control panel and operation hints for the key parts of the equipment enable the quick mastering of the operation;



The associated integration of the human engineering and structure design makes the equipment compact in structure , small in volume, light in weight, convenient and flexible in operation. It can be easily handled by one person and suitable for the operation under complicated environment.
